Speedrite A15Xi Mains Energiser

Description

The speedrite A15Xi provides the power previously attained from large energizer whilst complying with
the latest EN 60335 2 76 standard.

• Power

  • Powers up to 400 acres / 160 ha (270 km) of fence
  • 15 J maximum output energy (21 J stored energy)

3 Year Warranty

FEATURES AND BENEFITS

• Compatible with Speedrite Remote (Sold Separately)

•  Earth monitor LED illuminates orange when
the earth voltage is above 800 V.
• Earth monitor terminal should be connected in
the same way as 415i. Earth rod for earth
monitor needs to be 10m away from A15Xi’s
earth system.
• Notifies farmer when the earth system needs
to be improved to allow for adequate shocks
from the fence.

• Indicates when a medium or heavy load is
seen on the fence.
• Medium load LED illuminates orange when the
fence load is 100 Ω or less.
• Medium load and heavy load LEDs illuminate
orange when the fence load is 50 Ω or less.
• Notifies farmer when the fence needs to be
checked for high vegetation or shorts on the
fence.
